Installation Guide for Galaxy Power Systems
Issue 12 August 2012 AC Connection and Wiring 7 - 9
AC Input Panels Cross Reference, continued
Table 7-B2: AC Panels Cross Reference - GPS4812/24 and GPS2424/30 (208/240Vac)
Half / Full ac Feeds Rectifiers ED83142-30
H569-436
GPS4812/24
H569-437
GPS2424/30
AC Circuit Breaker Panels - 596A/B Rectifiers
H 1 8 6 71H 71H
F 1 12 7 72F 72F
F 1 8 6 73F 73F
H 1 w/N 8 6M 74H 74H
F 1 w/N 8 6M 74F 74F
AC Terminal Strip Panels - 596A/B Rectifiers
H 8 8 8 76H 76H
F 12 12 9 77F 77F
F 16 16 9 78F 78F*
Supplemental F 8 8 8 79F -
AC Circuit Breaker Panels - 596D Rectifiers
H 1 4 21 171H -
F 2 12 19 172F -
F 2 8 23 173F -
AC Terminal Strip Panels - 596D Rectifiers
H 4 4 22 175H -
H 8 8 22 176H -
F 12 12 20 177F -
F 16 16 20 178F -
F 8 8 22 179F -
Distribution Only Panels, no ac
None 28 28
*H569-437 G78F has 4 rectifier shelves but can support only 12 rectifiers. The additional positions (1 per
shelf) are for converter carriers.
Figures 7-4 through 7-20 illustrate the ac input panels.
