Installation Guide for Galaxy Power Systems
Issue 12 August 2012 Power Up and Installation Completion 15 - 13
Setting the System Float Voltage
Setting the System Float Voltage
Step Action
1 Enter the appropriate key sequence:
• Millennium Controller: 

Main
 Config  Rect Mngr  Enter (Basic)
Main  Config  Rect Mngr  Rect Oper Enter
(Intelligent)
• Vector Controller: 

Main Configuration  Float Voltages  Set Point
2 Verify that the HFV, HVSD, and SHVSD alarm thresholds are
set above the float voltage to be specified in Step 3.
3 Use the adjust keys to set the system float voltage. In
Millennium, the STEP field may be adjusted to 1V, .0.1V, or
0.01V to establish the voltage increments that the ADJ keys
use when setting the system float voltage.
