Installation Guide for Galaxy Power Systems
9 - 2 Converters Issue 12 August 2012
Installing the Converter Carrier
Refer to Figures 9-1 and 9-2 for the following procedure.
Installing the Converter Carrier
Step Action
1 Install converter carrier into the right-most position of the
top rectifier shelf (597A, 597B carriers). (See Figure 9-1.)


Note: If installing two carriers, connect the 848254654 cable
assembly to the first carrier and install the first carrier as
described below. Then, connect the cable to the second
carrier and install the second carrier as described below.

(See Figure 9-2.)
2 Tighten carrier onto shelf with 3/16-inch Allen wrench,
which has been provided.
3 • If this is the first carrier installed, it has been factory set to
the correct ID number, and no action is required on the
Converter Interface Card (CIC) to set the ID number.
• The ID numbers must be set when a second carrier is
installed. Proceed to the “Setting the CIC ID” procedure.
4 Do not install the converter cards at this time. See Section
15.
