Installation Guide for Galaxy Power Systems
16 - 2 Addition or Modification to a Galaxy Power System Issue 12 August 2012
Adding an
ED83143-31
Distribution Panel
to a GPS
Each ED83143-31 Distribution Panel is shipped with the following
components for installation in a Galaxy Power System. The quantity of
M5 mounting screws varies with the type and size of the panel being
installed, but the steps are the same.
Qty Comcode Description Fig. 16-1 Ref.
1 ED83143-31 Distribution Panel 2
901248815 Screw, HH Tap M5 x 12mm
7 901263327 Screw, HH M8 x 25mm
3 901249839 Nut, Hex, M8
7 901249813 Flat Washer, M8
7 901249821 Lock Washer, M8
1 848407888 Bus Bar 3
1 848407938 Bus Bar 4
1 848583720 Linking Bracket 5
1 848403481 Instruction Sheet
1 Varies Fuse/Breaker ID Label 7
1 Varies Extension Bracket (not with H569-434) 1
If a Load Return Bus is ordered, the following items are also included:
Qty Comcode Description Fig. 16-1 Ref.
4 901248815 Screw, HH Tap M5 x 12mm
3 901263327 Screw, HH M8 x 25mm
3 901249839 Nut, Hex, M8
3 901249813 Flat Washer, M8
3 901249821 Lock Washer, M8
1 848122586 or 848122594 Bus Bar 6
1 848418331 Bracket
2 996523080 Standoffs 6
2 901349274 Screw HWH 1/4-20 x 5/8
