Installation Guide for Galaxy Power Systems
8 - 2 DC Distribution Assembly and Connections Issue 12 August 2012
DC Distribution Panels Cross Reference
Table 8-A: DC Distribution Panels Cross Reference
Fuse or CB Pos.
Height
(in.) LVLD ED83143-31
H569-434 GPS4848/
100 H569-436 GPS4812/24 H569-437 GPS2424/30
CB/Fuse Small - TPA 14 6 11 40, 50, 40A, 50A 40A, 40B, 50A, 50B 40A, 40B, 50A, 50B
CB/Fuse Small - TPA 14 6 Y 11 45, 45A, 55, 55A 40C, 40D, 50C, 50D 40C, 40D, 50C, 50D
CB/Fuse Small - TPA 22 9 12 41, 51, 41A, 51A 41A, 41B, 51A, 51B 41A, 41B, 51A, 51B
CB/Fuse Small - TPA 22 9 Y 12 46, 46A, 56, 56A 41C, 41D, 51C, 51D 41C, 41D, 51C, 51D
CB Large 3 6 2 42, 42A, 106, 106A,
107, 107A, 108, 108A,
109, 109A 42A, 42B 42A, 42B
CB Large 3 6 Y 2 47, 47A 42C, 42D 42C, 42D
CB Large 5 9 5 48, 48A, 110, 110A,
111, 111A, 112, 112A,
113, 113A 44A, 44B 44A, 44B
CB Large 5 9 Y 5 48B, 48C 44C, 44D 44C, 44D
CB Large 6 12 1 43, 43A, 101, 101A,
102, 102A, 103, 103A,
104, 104A 43A, 43B 43A, 43B
CB Large 6 12 Y 1 43B, 43C 43C, 43D 43C, 43D
CB Bullet 10 6 15 96, 96A 46A, 46B 46A, 46B
CB Bullet 10 6 Y 15 96B, 96C 46C, 46D 46C, 46D
CB Bullet 14 6 16 97, 97A 47A, 47B 47A, 47B
CB Bullet 14 6 Y 16 97B, 97C 47C, 47D 47C, 47D
CB Bullet 22 9 17 98, 98A 48A, 48B 48A, 48B
CB Bullet 22 9 Y 17 98B, 98C 48C, 48D 48C, 48D
Fuse Medium 10 6 53 52, 52A 52A, 52B 52A, 52B
Fuse Medium 10 6 Y 53 52B, 52C 52C, 52D 52C, 52D
Fuse Large 2 6 56, 56A 59, 59A
Fuse Large 2 9 55 53, 53A 53A, 53B 53A, 53B
Fuse Large 2 9 Y 55 57, 57A 53C, 53D 53C, 53D
Fuse Large 5 9 54 54, 54A 54A, 54B 54A, 54B
Fuse Large 5 9 Y 54 54B, 54C 54C, 54D 54C, 54D
CB DIN Small 14 6 71/171 60, 60A 60A, 60B 60A, 60B
CB DIN Small 14 6 Y 71/171 60B, 60C 60C, 60D 60C, 60D
CB DIN Large 10 6 71/171 61, 61A 61A, 61B 61A, 61B
CB DIN Large 10 6 Y 71/171 61B, 61C 61C, 61D 61C, 61D
Fuse DIN 10 x 38mm 14 6 71/171 65, 65A 65A, 65B 65A, 65B
Fuse DIN 10 x 38mm 14 6 Y 71/171 65B, 65C 65C, 65D 65C, 65D
Fuse DIN 14 x 51mm 10 6 71/171 66, 66A 66A, 66B 66A, 66B
Fuse DIN 14 x 51mm 10 6 Y 71/171 66B, 66C 66C, 66D 66C, 66D
Fuse DIN NH00 8 6 22 67, 67A 67A, 67B 67A, 67B
Fuse DIN NH00 8 6 Y 22 67B, 67C 67C, 67D 67C, 67D
Fuse DIN NH2 2 6 21 68, 68A 68A, 68B 68A, 68B
Fuse DIN NH2 2 6 Y 21 68B, 68C 68C, 68D 68C, 68D
Small Fuse, 6-GMT 6 0 58 58 58 58
Blank Panel - 3 JD 93 93 93
Blank Panel - 6 JA 90 90 90
Blank Panel - 9 JB 91 91 91
Blank Panel - 12 JC 92 92 92
