Installation Guide for Galaxy Power Systems
Issue 12 August 2012 Addition or Modification to a Galaxy Power System 16 - 1
16 Addition or Modification to a
Galaxy Power System
Upgrading a
GPS4848 System to
a GPS4848/100
System A GPS4848/100 system is capable of producing 14,080 amperes of dc
power. Systems in the field can be upgraded to have this capability.
For a system to produce more than 4800 amperes, the following are
required:
• Controller software version 7.1.0 (or later)
• BLJ3 1:3 (or later) terminal board in cabinets with IDs above 8
• BIC8 (or later) bay interface card in cabinets with IDs above 8
• 595A2 or 595B2 (or later) rectifiers for rectifier IDs above 24
To upgrade an existing system, replace parts as needed until the above
requirements are met. Parts may be ordered from the H569-434

GPS4848/100 Ordering Guide.
