Installation Guide for Galaxy Power Systems
4 - Table of Contents Issue 12 August 2012
Connecting Cable Assembly to Thermal Probes 12-12
Monitoring a 210E Alarm Signal, BLJ-BIC7/8 with Millennium 12-13
13 Fascia Cover Installation
Introduction 13-1
Installing the Fascia Covers
13-2
14 Connection of Office Alarms
Introduction 14-1
Connecting Controller Alarms
14-1
15 Power Up and Installation Completion
Initial System Checkout and Preparation for Power Up 15-1
Controller Front Panels 15-1
Millennium 15-2
Vector 15-3
Initial Power Up of the System 15-4
Rectifier Installation Notes 15-4
Install First Rectifier 15-5
Install Converter Cards 15-6
Verify Controller 15-6
Set Rectifier ID 15-7
Installing Rectifiers and Converters 15-9
Lamp Test 15-11
Voltage Calibration 15-12
Setting the System Float Voltage 15-13
Setting the System Shunt 15-14
Setting the Low-Voltage Battery Disconnect Feature 15-15
Setting the Low-Voltage Load Disconnect Feature 15-17
Connecting Batteries 15-19
Testing Rectifiers and Load Share 15-21
Testing Temperature Compensation (Optional Feature) 15-22
Testing Additional Alarms 15-23
Testing the BD Alarm and High Voltage Shutdown 15-24
Galaxy Millennium Controller System Alarm Test 15-25
Connecting to Load 15-25
16 Addition or Modification to a Galaxy Power
System
Upgrading a GPS4848 System to a GPS4848/100 System 16-1
Adding an ED83143-31 Distribution Panel to a GPS 16-2
Installing an LVLD Contactor (if required) 16-5
Adding a Cabinet to an Existing GPS System with

Distributed Architecture. 16-6
