Installation Guide for Galaxy Power Systems
11 - 2 Battery Connection Panels Issue 12 August 2012
Battery Connection Panels Cross Reference
Table 11-A: Battery Connection Panels Cross Reference
Other LVBD Shunt ED83143-31
H569-434
GPS4848/100
H569-436
GPS4812/24
H569-437
GPS2424/30
No Battery Panel
None 33 33F 33F
Panels without Fuses or Circuit Breakers
3,000A 38/138 - 89F 89F
1,500A 30 32 - -
1,500A 40 - 88F -
HH 1,500A 137 - - 85H
1,500A 135 - - 85F
HH 1,000A 134 - - 84H
1,000A 35 - 85F -
HH 1,000A 37 - 85H -
HH 600A 34 - 84H -
2,000A 3,000A 36/136 39 39 39
1,200A 1,500A 31/131 31 31 31
HH 1,200A 1,500A 139 - - 32H
2 x 500A 2 x 600A 32/132 30 30 30
HH 1,200A 1,000A 133 - - 36H
HH 1,200A 1,000A 39 - 32H -
HH 1,200A 600A 33 - 36H -
Panels with Fuses or Circuit Breakers
2 x NH3 fuse
2 x 600A 41/141 34 34 34
1 x NH3 fuse 600A 42/142 35 35 35
2 x NH3 fuse 1,200A 2 x 600A 43/143 with
31/131
80 80 80
4 x NH3 fuse 1,200A 4 x 600A 2 x 43/143
with 31/131
81 81 81
6 x NH3 fuse 1,200A 6 x 600A 3 x 43/143
with 31/131
82 82 82
6 x breaker poles 63/163 86 86 86
6 x breaker poles 800A 64/164 87 87 87
Off Line Equalize Panels
1,200A 3 x 1,000A 60 37 37F -
3 x 1,000A 61 38 38F -
1. ED83143-31 group numbers less than 100 are -48Vdc and greater than 100 are +24V2.
2. HH indicates panels for Half Height Cabinets.
