Installation Guide for Galaxy Power Systems
Issue 12 August 2012 Power Up and Installation Completion 15 - 25
Galaxy Millennium Controller System Alarm Test
The Alarm Test provides a means of testing the operation of any or all
of the system alarm relays and their wiring to the connected alarm
system. The test cannot be performed if any alarms are active. In
addition, Rectifier HVSD (High Voltage Shut Down) and RFA
(Rectifier Fail Alarm) tests can be included. For additional information,
consult the Millennium Controller product manual.
Galaxy Millennium Controller System Alarm Test
Step Action
1 Connect all office alarm wiring from the controller’s office
alarm terminal block to the office alarm monitoring system.
2 Using either the factory hardware or software switch, enable
the Alarm Test feature.
a. Hardware: Enable DIP switch on the BSH board
b. Software: Use the following key sequence to get to the
menu with the software switch: 

Menu
 Config Alarm TEST ALA : ON (H,S)
3 Once the Alarm Test feature has been enabled, use the front
panel key sequence Menu
 Maint Oper Alarm Test
Enter to start the Alarm Test.
Connecting to Load
The system is ready to connect to equipment loads. Install or turn on
load protectors when needed.
