Procedure, Procedure 5-15, Cabinet installation, continued – GE Industrial Solutions Galaxy Power Systems User Manual
Page 61
Installation Guide for Galaxy Power Systems
Issue 12 August 2012
Cabinet Floor Mounting and Battery Stand Connection 5 - 15
Cabinet Installation, continued
Procedure
Refer to Figure 5-12 for this procedure.
Cabinet Installation
Step
Action
1
Position the appropriate drill template where the cabinet is
to be located.
Comcode of
Template
For:
847891280
GPS4812/24, GPS2424/30, or GPS4848/100
846898708
2VR375 Battery Stand
846736841
2VR250 Battery Stand
847733342
12IR125LP Battery Stand
2
Using a drill bit, drill anchor holes to the depths specified in
Table 5-B.
3
Locate the cabinet in position using two or four anchor
bolts and hold-down washers.
4
Shim under cabinet corners to level.
5
Torque anchors as specified in Table 5-B.
6
Secure cabinets together using the hardware provided.
Note: See H569-407 for more details.
