Installation Guide for Galaxy Power Systems
7 - 2 AC Connection and Wiring Issue 12 August 2012
Wire Sizing and Ampacity
Table 7-A: Wire Sizing and Ampacity
Standard Ga Metric (mm 2 )
NEC Table 310-16
75°C (A) (see Note)
10 6 35
8 10 50
6 16 65
4 25 85
2 35 115
1/0 50 150
2/0 70 175
4/0 120 230
Note: For NEC code compliance, all wire sizing calculations are made assuming
75°C rated wire. Lineage Power recommends the use of 90°C rated wire, which
has a higher current carrying capacity, for all ac connections.
Figure 7-15 ED83142-30 Group 18 (H569-434 G128, G129, G130, G131,
G224, G226, G330, G331) AC Input Panel for 595A or 595B
Series Rectifiers
Figure 7-16 ED83142-30 Group 26 (H569-434 G328, G329, G332, G131,
G333) AC Input Panel for 595LTA or 595LTB Series Rectifiers
Figure 7-17 ED83142-30 Group 19 (H569-436 G172F) AC Input Panel for
596D Series Rectifiers
Figure 7-18 ED83142-30 Group 20, 22 (H569-436 G175H, G176H, G177F,
G178F, G179F) AC Input Panel for 596D Series Rectifiers
Figure 7-19 ED83142-30 Group 21 (H569-436 G171H) AC Input Panel for
596D series Rectifiers
Figure 7-20 ED83142-30 Group 23 (H569-436 G173F) AC Input Panel for
596D Series Rectifiers
Figure 7-21 Neutral AC Input for ED83142-30 G6, G7, G19, G21 or G23
H569-436 G71H, G72F, G73F, G171H, G172F, G173F; H569-437
G71H, 72F, or G73F
Figure 7-22 Bottom Cable Feed Option for GPS4848/100
