Connection of office alarms, Introduction, Connecting controller alarms – GE Industrial Solutions Galaxy Power Systems User Manual
Page 181: 14 connection of office alarms, Introduction 14-1 connecting controller alarms
Installation Guide for Galaxy Power Systems
Issue 12 August 2012
Connection of Office Alarms 14 - 1
14
Connection of Office Alarms
Introduction
This section explains the installation procedure to connect the office
alarms.
Connecting Controller Alarms
Connecting Office Alarms
Step
Action
1
Choose the appropriate illustration from the following list:
• Figure 14-1: Galaxy Millennium Controller with
Insulation Displacement Alarm Board
• Figure 14-2: Galaxy Millennium Controller with Wire
Wrap Alarm Board
• Figure 14-3: Galaxy Vector Controller with Insulation
Displacement Alarm Board
2
Route wires (installer provided, 22-gauge maximum) from
the office alarm block back to the controller by following
the numbered sequence of steps on the illustration.
