Installation Guide for Galaxy Power Systems
Issue 12 August 2012 Remote Peripheral Monitoring 10 - 1
10 Remote Peripheral Monitoring
Overview
Note: The Remote Peripheral Monitoring feature is not available on
the Galaxy Vector Controller.
RPM Modules The Remote Peripheral Monitoring measurement and control modules
provide data acquisition and control functions for a power environment.
System capacity is added in a modular fashion with measurement and
control modules. Each measurement module consists of six input
channels and one temperature channel. A temperature module has seven
channels to measure the temperature of seven different points in the
system. A control module provides three separate control relays. The
modules, which communicate back to the controller, are physically
connected in a daisy-chain bus configuration. The user can program
various alarm and control functions with the modules when used with a
Galaxy Millennium controller.
Table 10-A lists the RPM modules.
Table 10-A: RPM Modules and Connection Units
Module Type(s) Module Code(s)
Module and Connection
Unit Kit Comcode
Control Relay 214A 108298456
Voltage (0-3Vdc) 221A 108298431
Voltage (0-16Vdc) 221B 108298498
Voltage (0-70Vdc) 221C 108469503
Voltage (0-200Vdc) 221D 108469479
Shunt 221F 108469461
Transducer 221J 108469495
Binary 222A 108298449
Temperature 223T 108274242
