Page 37: 3getting started
Installation Guide for Galaxy Power Systems
Issue 12 August 2012
Getting Started 3 - 1
3
Getting Started
Tools and
Hardware
You will need the following tools and hardware to install the Galaxy
Power System:
• Material-handling equipment to unload the cabinet at the installation
site, remove from shipping container, and set in final position
[minimum lifting capacity: 900 lbs. (410Kg)] Note: Use the
equipment weights and dimensions as a guideline for choosing
material-handling equipment.
• Drill and drill bits to install floor anchors
• 3/16-inch (5mm) Allen-head wrench (provided)
• Insulated hand tools
• Screw drivers (flat-blade and Phillips)
• Wire cutters and stripper
• Torque wrenches (see Table 3-A)
35-513 in·lbs (4-58 N·m)
• Sockets:
Metric
English Equivalent Hardware
8mm
5/16"
M5
10mm
--
M6
13mm
1/2"
M8
17mm
11/16"
M10
19mm
3/4"
M12
--
3/8"
1/4"
--
9/16"
3/8"
