5: Schematic View
88 000-20000-300-02-201312
Notes:
►
Procedure
When connecting the Phtmet node,
1. Wire the Absolute Irradiance Unit Converter node.
2. Connect the Constant (Const) node.
Within the Phtmet node, you can alter the observer parameters and solid angle. For observer, use Photopic
or Photopic (Modified) for high-light conditions and Scotopic for low-light conditions. The solid angle is
set in the box marked Steradian.
Power (Pwr)
Outputs the input data raised to the specified power.
Location: Basic Math-->Power
Number of Inputs: 2
Type of Inputs: base: scalar or array; exponent: scalar only
Type of Output: scalar or array
User Controls: Swap Inputs
Notes: The first input that is connected is the base and the second input that is connected is the exponent.
Reflective Color (Refl Color)
Applies user-configured parameters of Observer and Illuminant type to input data from a Reflection Unit
Labels node.
Location: Color Math -->Reflective Color
Number of Inputs: 1
Type of Inputs: array from Unit Labels (Units) node (Reflection)
Type of Output: data must be output to Color View or a color parameter calculation node for further
processing
User Controls: Observer, Illuminant type
