3: User Interface
000-20000-310-02-201312 29
File Options:
Field Selections
Save to directory Type in or browse to the desired directory
File Format Tab sep. with Headers, Tab separated data, or Columned data
Padding digits
The number of digits to be used when appending to a file (enter 3
to save hundreds of files, enter 4 to save thousands, etc. up to 15),
for example: spectrumfile001 through spectrumfile999 if 3 is
selected
BaseName
Added in front of the file name for a better description of the saved
session
Preview example Displays a preview version of the file
Once the saving of graph data has been configured, you can save the graph data to a file or files.
Graph Layer Options Window
Select the Graph layer options by clicking .
The Graph Layer options are divided into the following functions, each accessed in its own window:
• General Window
• Keymap Window
• Miscellaneous Window
• Graph Layer Window
