3: User interface
20 000-20000-300-02-201312
Use this dialog box to perform the following functions:
• Connect/disconnect the device from OceanView
• Add another device to OceanView
• Rescan for devices
• Simulate a device
• Automatically connect to the device when it is attached to the network
Acquisition Parameter Controls
Acquisition parameters allow you to establish signal-conditioning settings for your processed data. By
using the graph real-time display of data you can evaluate the effectiveness of your experimental setups
and data processing selections, make changes to these parameters, instantly see the effects and save the
data. The options available can change based on device.
The Acquisition Control Panel is accessed in the Graph View window by clicking the Acquisition
Controls button ( ).
The Acquisition Control Panel can also be accessed in the Schematic window by clicking the Acquisition
Controls node ( ).
When you click the Acquisition Controls button in the Graph or Schematic View, the Main Controls tab
of the Acquisition Parameters Controls opens.
