5: Schematic View
80 000-20000-300-02-201312
Energy, Power, Photons (EPP)
Calculates and outputs radiometric quantities for an absolute irradiance-calibrated spectrometer.
Location: Advanced Math -->Array Math --> Energy, Power, Photons
Number of Inputs: 2
Type of Inputs: Unit Labels node (Absolute Irradiance), Data Property (DataProp) (Integration Time)
Type of Output: Data must be output to a Table View.
User Controls: Integration endpoints and method
Notes:
► Procedure
When connecting the EPP node you must,
1. Wire the Absolute Irradiance Unit Converter node.
2. Connect the Data Property (DataProp) node. The Data Property (DataProp) node should be set to
output Integration Time.
Within the EPP node, you may alter the integration method and endpoints.
Evaluate Function (FnEval)
The Function Evaluator outputs the y value of a polynomial function based on the x value input and the
polynomial coefficients.
Location: Advanced Math -->Array Math --> Evaluate Function
Number of Inputs: 2
Type of Inputs: 1 Regression node and 1 scalar
Type of Output: scalar
User Controls: N/A
Notes:
►
Procedure
When connecting to the FnEval node,
1. Wire the scale coefficient information from a Regression node.
2. Connect the scalar x value.
