2. After the starting and ending values have been set, click Apply. This sets the SubRange nodes to
the correct values for each array. After clicking Apply, note that the individual graphs for each
data array rescale to the values you have set.
3. To enlarge the x-axis data range for a particular array after clicking Apply, click the Full Range
button next to the graph. The graph for that array returns to its maximum endpoint values.
4. To remove a SubRange completely, click the X button next to the graph for the appropriate array.
5. To finish, click Exit.
The output of a Splice node can be fed into any node that will accept an array. Note that the Add Range
button is only used when using the Splice Wizard.
Square Root (SqRt)
Outputs the square root of the input.
Location: Basic Math -->Square Root
Number of Inputs: 1
Type of Inputs: scalar or array
Type of Output: scalar or array
User Controls: N/A
Standard Deviation (StdDev)
Outputs the standard deviation of an array of data.
Location: Basic Math-->Standard Deviation
Number of Inputs: 1
Type of Inputs: array
Type of Output: scalar
User Controls: N/A
SubRange (SubRng)
Limits the x-axis bounds of an array and outputs the truncated array.
