5: Schematic View
74 000-20000-300-02-201312
User Controls: N/A
CIE u'v'w' (u'v'w')
Outputs the CIE 1976 u'v'w' color space values based on the input data.
Location: Color Math -->u'v'w'
Number of Inputs: 1
Type of Inputs: EmissChrom node or ReflChrom node
Type of Output: 5 scalar coefficients (u', v', w', huv, suv)
User Controls: N/A
CIE uv (uv)
Outputs the CIE 1960 uv color space values based on the input data.
Location: Color Math -->uv
Number of Inputs: 1
Type of Inputs: EmissChrom node or ReflChrom node
Type of Output: 2 scalar coefficients (u, v)
User Controls: N/A
CIE xyz (xyz)
Outputs the CIE 1931 x, y,and z chromaticity coordinates based on the input data.
Location: Color Math -->xyz
Number of Inputs: 1
Type of Inputs: EmissChrom node or ReflChrom node
Type of Output: 3 scalar coefficients (x, y, z)
User Controls: N/A
