5: Schematic View
000-20000-310-02-201312 85
Natural Logarithm -- base e (Ln)
Outputs the natural logarithm of the input.
Location: Basic Math -->Natural Logarithm
Number of Inputs: 1
Type of Inputs: scalar or array
Type of Output: scalar or array
User Controls: N/A
Negate (Neg)
Changes the sign of the input data. Positive values become negative and negative values become positive.
Location: Basic Math-->Negate
Number of Inputs: 1
Type of Inputs: scalar or array
Type of Output: scalar or array
User Controls: N/A
Output Control (Output Control)
Enables adjustment of certain spectrometer settings using the output of other schematic nodes.
Location: Right-click a Spectrometer icon and choose one of the options under the New Output Control
menu.
Number of Inputs: 1
Type of Inputs: scalar
Type of Output: Scalar to spectrometer node.
User Controls: Depends on the type of control output.
Notes: Different types of output controls are available for different devices. Output control choices may
include Strobe/Lamp Enable, GPIO, Single Strobe, External Trigger Delay, Continuous Strobe,
Acquisition Delay, and Analog-Out.
