Appendix 1 - Default parameters
All values are default values and can alter from application to application.
Abbreviations:
- no effect because NU I only for Info
C Calibration value D Design Value
Hoist Control:
Load Measurement: 2 Speeds
Motor
2 Speeds
Sensor
Inverter
Sensor
Hoist Control:
Load Measurement: 2 Speeds
Motor
2 Speeds
Sensor
Inverter
Sensor
3 Load Setup 4 Start-up, continue
3-2-1 Load 1 C - - 4-7-10 C1F D - -
3-2-2 Mhs1 C - - 4-7-11 C1S D - -
3-2-3 Mhf1 C - - 4-7-12 ki D - -
3-2-4 Mls1 C - - 4-7-13 Acc-t slow 0.2 0.2 -
3-2-5 Mlf1 C - - 4-7-14 Acc-t fast 0.3 0.3 -
3-2-6 Load 2 C - - 4-8 Hoist ctrl 2-SP 2-SP INV
3-2-7 Mhs2 C - - 4-9-1 SR select NU NU NU
3-2-8 Mhf2 C - - 4-9-2 Load limit - - -
3-2-9 Mls2 C - - 4-10-1 OT run? No No No
3-2-10 Mlf2 C - - 4-10-2 OT limit - - -
3-4-1 Load 1 - C C 4-10-3 Supply sup No No No
3-4-2 Input 1 - C (~2) C (~2) 4-11-1 Hoist cnt 1 1 1
3-4-3 Load 2 - C C 4-11-2 Run sup. No No No
3-4-4 Input 2 - C (~5) C (~5) 4-11-3 B OL No No No
3-5 OL protect On On On 4-11-4 B nom load Single hoist use value from 6.4
4 Start-up 5 Service
4-1-1 MFI1 oper. NU NU NU 5-1-1 S run time For Service. If not used, use value 6-9.
4-1-2 MFI1 IntL - - - 5-1-2 S starts For Service. If not used, use value 6-7.
4-1-3 MFI 2OLL - - - 5-1-3 S SWP For Service. If not used, use value 0.
4-1-4 MFI1 Cintl - - - 5-1-4 S Br SWP% For Service. If not used, use value 0.
4-2-1 MFI2 oper. NU NU NU 5-2 Fault log
4-2-2 MFI2 IntL - - - 5-2-1 FAULT1 I I I
4-2-3 1 + 2 IntL - - - 5-2-2 ST1 I I I
4-2-4 MFI2 2OLL - - -
4-2-5 MFI2 CIntL - - - 6 Design
4-2-6 1 + 2 CIntL - - - 6-1 Hoist name A A A
4-3-1 ROUT oper. OL OL OL 6-2 Unit No I I I
4-3-2 ROUT Logic Norm Norm Norm 6-3 Class I I I
4-3-3 ROUT LoadX - - - 6-4 Nom. Load D D D
4-3-4 TempX meas - - - 6-5 Nominal ED D D D
4-3-5 TempX lim - - - 6-6 Sp ratio 6 6 1
4-4-1 T1 operat. B NTC NU NU 6-7 Max ST D D D
4-5-1 T2 operat. B NTC NU NU 6-8 Max E-stop 5000 5000 5000
4-6-1 AOUT oper. NU NU NU 6-9 Max RT D D D
4-6-2 Zero load - - - 6-10 D SRT3 D D D
4-6-3 Nom. Load - - - 6-11 D SRT8 D D D
4-7-1 Load Meas. Motor Sensor Sensor 6-12 D SL3 D D D
4-7-2 Load rate% 10,00 10 - 6-13 D SL8 D D D
4-7-3 R0_F D - - 6-14 MaxST MFI1 D D D
4-7-4 R0_S D - - 6-15 MaxRT MFI1 D D D
4-7-5 T0 D - - 6-16 MaxST MFI2 D D D
4-7-6 TEMP_SLOW D - - 6-17 MaxRT MFI2 D D D
4-7-7 TEMP_FAST D - - 6-18 Max Br 1M000 1M000 D
4-7-8 C2F D - - 6-19 MaxControl 640k0 640k0 640k0
4-7-9 C2S D - - 6-20 Password D D D
