• Check, from el.drawings if any by-pass function is designed. If yes, continue. (Designer might have
activated slack ropes by-pass function parameter but the connections in el.drawings are done only
when ordered.)
• Activate the input and lower the hook.
• The motion should run.
9.4 Commissioning table
Read the below parameters from the display and write them down in the table
Keep this sheet in a safe place for future reference.
Hoist serial number: Date:
Hoist monitoring unit serial
number:
Name:
Param. Name Value Param. Name Value
0-2 Hoist name 4 Start-up
1 Monitor 1 4-1-1 MFI1 oper.
1-2-4 Supply L1 4-1-2 MFI1 IntL
1-2-5 Supply L2 4-1-3 MFI1 2OLL
1-2-6 Supply L3 4-1-4 MFI1 CintL
1-2-16 Supply f 4-2-1 MFI2 oper.
2 Monitor 2 4-2-2 MFI2 IntL
2-1 SW version 4-2-3 1+2 IntL
3 Load setup 4-2-4 MFI2 2OLL
3-2-1 Load 1 4-2-5 MFI2 CintL
3-2-2 Mhs1 4-2-6 1+2 CintL
3-2-3 Mhf1 4-3-1 ROUT oper.
3-2-4 Mls1 4-3-2 ROUT logic
3-2-5 Mlf1 4-3-3 ROUT LoadX
3-2-6 Load 2 4-3-4 TempX meas
3-2-7 Mhs2 4-3-5 TempX lim
3-2-8 Mhf2 4-4-1 T1 operat.
3-2-9 Mls2 4-5-1 T2 operat.
3-2-10 Mlf2 4-6-1 AOUT oper.
3-4-1 Load 1 4-6-2 Zero load
3-4-2 Input 1 4-6-3 Nom. Load
3-4-3 Load 2 4-7-1 Load meas.
3-4-4 Input 2 4-7-2 Load rate%
4-7-13 Acc-t slow
4-7-14 Acc-t fast
4-8 Hoist ctrl
4-9-1 SR select
4-9-2 Load limit
4-10-1 OT run ?
4-10-2 OT limit
4-10-3 Supply sup
4-11-1 Hoist cnt
4-11-2 Run sup.
4-11-3 B OL
4-11-4 B nom load
The hoist-monitoring unit has been tested and proven fully functional.
