6.3 Measured values
The measured values allows maintenance analysis.
A dot will appear on the correct spot to indicate the decimals
Param. Name Value Description
1-2 Measure Measurement menu
1-2-1 Act. Load “n.n” t The measured actual load value of the solo hoist connected to the unit.
1-2-2 Temp 1 “nnn” C
Temperature measured at thermistor input 1. Only functional when par. 4-4-1 is set to “”x”NTC”
and a NTC-type of thermistor is connected across terminals X2: 21-22. Otherwise the display
shows “NA” (Not Available)
1-2-3 Temp 2 “nnn” C
Temperature measured at thermistor input 2. Only functional when par. 4-5-1 is set to “”x”NTC”
and a NTC-type of thermistor is connected across terminals X2: 23-24. Otherwise the display
shows “NA” (Not Available)
1-2-4 Supply L1 “nnn” V RMS line voltage of phase L1, measured at terminal X1: 19; VAC
1-2-5 Supply L2 “nnn” V RMS line voltage of phase L2, measured at terminal X1: 17; VAC
1-2-6 Supply L3 “nnn” V RMS line voltage of phase L3, measured at terminal X1: 15; VAC
1-2-7 Motor I1 “nn.n” A RMS motor current of phase U. Only functional when par. 4-7-1 is set to “Motor”
1-2-8 Motor I2 “nn.n” A RMS motor current of phase V. Only functional when par. 4-7-1 is set to “Motor”
1-2-9 Motor I3 “nn.n” A RMS motor current of phase W. Only functional when par. 4-7-1 is set to “Motor”
1-2-10 Ain1 value “n.nn” V Measured voltage at analogue input AIN1. Voltage across terminals X2: 26-30; VDC
1-2-11 Ain2 value “n.nn” V Measured voltage at analogue input AIN2. Voltage across terminals X2: 27-30; VDC
1-2-12 Ain3 value “n.nn” V
Measured voltage at analogue input AIN3. Note that there is no function behind AIN3. This input
can be used for measurement purposes only
1-2-13 Int. temp “n” C Internal temperature of the unit.
1-2-14 Input i.e.: 10101
Indicates the status of the inputs: HIN, LIN, FIN, MFI1 & MFI2. “1” means active, “0” means
inactive. Note that the leftmost “zeros” before the first appearing “1” are not displayed
1-2-15 Output i.e.: 10100
Indicates the status of the outputs: HOUT, LOUT, FOUT, RS & ROUT. “1” means active, “0”
means inactive. Note that the leftmost “zeros” before the first appearing “1” are not displayed
1-2-16 Supply f 50 Supply voltage frequency (50 or 60Hz)
Param. Name Value Description
1-3 Min/Max Minimum / maximum value menu
1-3-1 Min supply “nnn” V Minimum measured value of the supply line voltage RMS.
1-3-1 Reset ? “nnn” V Resets the value shown in parameter 1-3-1 by pushing the ENT button twice
1-3-2 Max supply “nnn” V Maximum measured value of the supply line voltage RMS.
1-3-2 Reset ? “nnn” V Resets the value shown in parameter 1-3-2 by pushing the ENT button twice
1-3-3 Min Int. T “n” C Minimum measured value of the internal temperature of the unit.
1-3-3 Reset ? “n” C Resets the value shown in parameter 1-3-3 by pushing the ENT button twice
1-3-4 Max Int. T “n” C Maximum measured value of the internal temperature of the unit.
1-3-4 Reset ? “n” C Resets the value shown in parameter 1-3-4 by pushing the ENT button twice
