Parameter Value Description Note
4-7-13
Acc-t slow 0.20s Acceleration time from stop to slow speed 0.00s –
1.00s See also chapter “Starting and stopping through slow
speed” of this manual
4-7-14
Acc-t fast 0.30s Acceleration time from slow speed to fast speed 0.00s
– 1.00s See also chapter “Starting and stopping through slow
speed” of this manual
Parameter Value Description Note
6
Design In this menu are the mechanical design values of
the hoist determined. Accessible with password 6: 9822
6-4
Nom. Load 0.00- 999t Rated load of the hoist. Setting according to the data label of the hoist
In case the automatic load calibration sequence does not give the required result (i.e. the difference
between the actual load and the calculated/displayed load is more than 10%), the unit can be calibrated
manually with the following parameters. Refer to paragraph “Manual load calibration” of this chapter for
further instructions.
Parameter Value Description Note
3-2
MC values Load calibration value for the motor torque method Accessible with password 2: 0732
3-2-1
Load 1 0.00- 999t The higher test load value (80% – 130%) × Hoist
nominal Load [tons]
3-2-2
Mhs1 “nn.nn” Motor torque for hoisting with slow speed (test load) The value “n” depends on the motor type. The calibration
procedure will automatically write the correct value.
3-2-3
Mhf1 “nn.nn” Motor torque for hoisting with fast speed (test load) The value “n” depends on the motor type. The calibration
procedure will automatically write the correct value.
3-2-4
Mls1 “-nn.nn” Motor torque for lowering with slow speed (test load) The value “n” depends on the motor type. The calibration
procedure will automatically write the correct value.
3-2-5
Mlf1 “-nn.nn Motor torque for lowering with fast speed (test load) The value “n” depends on the motor type. The calibration
procedure will automatically write the correct value.
3-2-6
Load 2 0.00t The lower test load value, usually the empty hook
(0.00t). A load in the range of 0…30% × hoist nominal load can be
used
3-2-7
Mhs2 “nn.nn” Motor torque for hoisting with slow speed (load 2) The value “n” depends on the motor type. The calibration
procedure will automatically write the correct value.
3-2-8
Mhf2 “nn.nn” Motor torque for hoisting with fast speed (load 2) The value “n” depends on the motor type. The calibration
procedure will automatically write the correct value.
3-2-9
Mls2 “-nn.nn Motor torque for lowering with slow speed (load 2) The value “n” depends on the motor type. The calibration
procedure will automatically write the correct value.
3-2-10
Mlf2 “-nn.nn Motor torque for lowering with fast speed (load 2) The value “n” depends on the motor type. The calibration
procedure will automatically write the correct value.
