4.1 Passwords
The table below indicates the access to the menus with different password levels.
The display asks for the password when the ENT button is pushed in the main load display mode. If the
given password does not match to any of the levels, the display returns to the main load display mode. If
the given password matches to one of the levels, the user has access to the corresponding menus
according to the table below.
Main menus Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 Level 7
1 Monitor 1 X X X X X X
2 Monitor 2 X X X X X
3 Load Setup X X X X X
4 Start-up X X X X
5 Service X X X
6 Design X X
7 GO-setup X
Passwords for different levels
Level Password Note
Level 1 Parameter Given with the parameter, 6–20 Password
Level 2 0732 Fixed value, can only calibrate the load measurement
Level 3 5201 Fixed value, used to read the monitoring values
Level 4 8124 Fixed value, all menus up to input/output settings and calibration
Level 5 5029 Fixed value, all menus up to service menu
Level 6 9822 Fixed value, all menus up to design limit values
Level 7 2180 Fixed value, access to all parameters
