16.4 Start-up menu (Menu 4)
4 Start-up Start- menu. Accessible password level 4
Param. Name Value Description
4-1 MFI1 Multi-Functional Input 1 parameters
Selects the function of MFI1:
NU
Not used
IntL Intermediate load limit
Tare Load tare
SRope Slack rope by-pass
ST/RT Start and run-time counter
2OLL Second overload limit
Level Levelling limit switch function in common hoisting
CintL Intermediate load limit in common hoisting
4-1-1 MFI1 oper. NU
CAN CAN bus by-pass
4-1-2 MFI1 IntL ”nn.n” t
When “IntL” is chosen with parameter 4-1-1, the (first) intermediate load limit value is entered here (in
tons). Range: 0…hoist rated load
4-1-3 MFI1 2OLL ”n.nn”
When 2OLL is chosen with parameter 4-1-1, the coefficient for the second load limit is entered here.
Range: 1.00…1.30
4-1-4 MFI1 CintL “nn.n” t
When “CintL” is chosen with parameter 4-1-1, (the first) bridge intermediate load limit value is entered
here (in tons). Range: 0…bridge rated load
Param. Name Value Description
4-2 MFI2 Multi-Functional Input 2 parameters
Selects the function of MFI2:
NU
Not used
IntL Intermediate load limit
Tare Load tare
SRope Slack rope by-pass
ST/RT Start and run-time counter
2OLL Second overload limit
Level Levelling limit switch function in common hoisting
CintL Intermediate load limit in common hoisting
4-2-1 MFI2 oper. NU
CAN CAN bus by-pass
4-2-2 MFI2 IntL ”nn.n” t
When “IntL” is chosen with parameter 4-2-1, the (second) intermediate load limit value is entered here
(in tons). Range: 0…hoist rated load
4-2-3 1+2 IntL “nn.n” t
When “IntL” is chosen with both parameters 4-1-1 and 4-2-1, the third intermediate load limit value is
entered here (in tons). Range: 0…hoist rated load
4-2-4 MFI2 2OLL ”n.nn”
When 2OLL is chosen with parameter 4-2-1, the coefficient for the second load limit is entered here.
Range: 1.00…1.30
4-2-5 MFI2 CintL “nn.n” t
When “CintL” is chosen with parameter 4-2-1, the (second) bridge intermediate load limit value is
entered here (in tons). Range: 0…bridge rated load
4-2-6 1+2 CintL “nn.n” t
When “CintL” is chosen with both parameter 4-1-1 and 4-2-1, the third bridge intermediate load limit
value is entered here (in tons). Range: 0…bridge rated load
Param. Name Value Description
4-3 ROUT Relay output parameters
Selects the function of the relay output
NU
Not used
OL
Overload: Hoist in overload; contact closed
Bridge in overload; contact closed; since SW 2.100
LoadX Load limit: Load greater than limit set by parameter 4-3-3; contact closed
OK
Normal; contact closed.
Warning; contact blinks.
Fault; contact open
Ready
Normal; contact closed.
Fault; contact open
4-3-1 ROUT oper. NU
TempX Temperature limit: Temperature greater than limit set by parameter 4-3-4; contact closed
4-3-2 ROUT logic Norm
The operation logic of the relay:
Norm
Normal operation as described above (4-3-1)
Inv Operation inverted compared to the description above (4-3-1)
