Register 0x28 (IEEE_ADDR_4):
This register contains 8 bit of the MAC IEEE address for Frame Filter address recognition, bits
[39:32].
Register 0x29 (IEEE_ADDR_5):
This register contains 8 bit of the MAC IEEE address for Frame Filter address recognition, bits
[47:40].
Register 0x2A (IEEE_ADDR_6):
This register contains 8 bit of the MAC IEEE address for Frame Filter address recognition, bits
[55:48].
Register 0x2B (IEEE_ADDR_7):
This register contains the higher 8 bit of the MAC IEEE Frame Filter address for address recog-
nition, bits [63:56].
Bit
7
6
5
4
3
2
1
0
+0x28
IEEE_ADDR_4[7:0]
IEEE_ADDR_4
Read/Write
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset Value
0
0
0
0
0
0
0
0
Bit
7
6
5
4
3
2
1
0
+0x29
IEEE_ADDR_5[7:0]
IEEE_ADDR_5
Read/Write
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset Value
0
0
0
0
0
0
0
0
Bit
7
6
5
4
3
2
1
0
+0x2A
IEEE_ADDR_6[7:0]
IEEE_ADDR_6
Read/Write
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset Value
0
0
0
0
0
0
0
0
Bit
7
6
5
4
3
2
1
0
+0x2B
IEEE_ADDR_7[7:0]
IEEE_ADDR_7
Read/Write
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset Value
0
0
0
0
0
0
0
0
