Note that AWAKE_END interrupt can usually not be seen when the transceiver enters
TRX_OFF state after RESET, because register 0x0E (IRQ_MASK) is reset to mask all inter-
rupts. In this case, state TRX_OFF is normally entered before the microcontroller could modify
the register.
The interrupt handling in Extended Operating Mode is described in
If register bit IRQ_MASK_MODE (register 0x04, TRX_CTRL_1) is set, an interrupt event can be
read from IRQ_STATUS register even if the interrupt itself is masked. However, in that case no
timing information for this interrupt is provided.
The IRQ pin polarity can be configured with register bit IRQ_POLARITY (register 0x04,
TRX_CTRL_1). The default behavior is active high, which means that pin IRQ = H issues an
interrupt request.
If "Frame Buffer Empty Indicator" is enabled during Frame Buffer read access the IRQ pin has
an alternative functionality, refer to
Section 11.7 “Frame Buffer Empty Indicator” on page 152
for
details.
6.6.2
Register Description
Register 0x0E (IRQ_MASK):
he IRQ_MASK register is used to enable or disable individual interrupts. An interrupt is enabled
if the corresponding bit is set to 1. All interrupts are disabled after power up sequence (P_ON
state) or reset (RESET state).
If an interrupt is enabled it is recommended to read the interrupt status register 0x0F
(IRQ_STATUS) first to clear the history.
Register 0x0F (IRQ_STATUS):
The IRQ_STATUS register contains the status of the pending interrupt requests.
By reading the register after an interrupt is signaled at pin 24 (IRQ) the source of the issued
interrupt can be identified. A read access to this register resets all interrupt bits, and so clears
the IRQ_STATUS register.
If register bit IRQ_MASK_MODE (register 0x04, TRX_CTRL_1) is set, an interrupt event can be
read from IRQ_STATUS register even if the interrupt itself is masked. However in that case no
timing information for this interrupt is provided.
If register bit IRQ_MASK_MODE is set, it is recommended to read the interrupt status register
0x0F (IRQ_STATUS) first to clear the history.
Bit
7
6
5
4
3
2
1
0
+0x0E
MASK_BAT_LOW
MASK_TRX_UR
MASK_AMI
MASK_CCA_ED_READY
MASK_TRX_END
MASK_RX_START
MASK_PLL_UNLOCK
MASK_PLL_LOCK
IRQ_MASK
Read/Write
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset Value
0
0
0
0
0
0
0
0
Bit
7
6
5
4
3
2
1
0
+0x0F
BAT_LOW
TRX_UR
AMI
CCA_ED_READY
TRX_END
RX_START
PLL_UNLOCK
PLL_LOCK
IRQ_STATUS
Read/Write
R
R
R
R
R
R
R
R
Initial Value
0
0
0
0
0
0
0
0
