• Bit [3:0] - BATMON_VTH

The threshold values for the battery monitor are set by register bits BATMON_VTH:

Table 9-11.

Battery Monitor Threshold Voltage

Value

BATMON_VTH[3:0]

Voltage [V]

BATMON_HR = 1

Voltage [V]

BATMON_HR = 0

0x0

2.550

1.70

0x1

2.625

1.75

0x2

2.700

1.80

0x3

2.775

1.85

0x4

2.850

1.90

0x5

2.925

1.95

0x6

3.000

2.00

0x7

3.075

2.05

0x8

3.150

2.10

0x9

3.225

2.15

0xA

3.300

2.20

0xB

3.375

2.25

0xC

3.450

2.30

0xD

3.525

2.35

0xE

3.600

2.40

0xF

3.675

2.45
