AT86RF231
Note:
Register values 1 and 2 are valid for ANT_EXT_SW_EN = 1.
Table 11-14. Antenna Diversity Switch Control
Register Bit
Value
Description
ANT_CTRL
0
Reserved
1
Antenna 1
DIG1 = H
DIG2 = L
2
Antenna 0
DIG1 = L
DIG2 = H
3
Default value for ANT_EXT_SW_EN = 0.
Mandatory setting for applications not using Antenna Diversity.
