Page 76
76
8111A–AVR–05/08
AT86RF231
7.2.8
Register Description - Address Registers
Register 0x20 (SHORT_ADDR_0):
This register contains the lower 8 bit of the MAC short address for Frame Filter address recogni-
tion, bits [7:0].
Register 0x21 (SHORT_ADDR_1):
This register contains the higher 8 bit of the MAC short address for Frame Filter address recog-
nition, bits [15:8].
Register 0x22 (PAN_ID_0):
This register contains the lower 8 bit of the MAC PAN ID for Frame Filter address recognition,
bits [7:0].
Register 0x23 (PAN_ID_1):
This register contains the higher 8 bit of the MAC PAN ID for Frame Filter address recognition,
bits [15:8].
Bit
7
6
5
4
3
2
1
0
+0x20
SHORT_ADDR_0[7:0]
SHORT_ADDR_0
Read/Write
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset Value
1
1
1
1
1
1
1
1
Bit
7
6
5
4
3
2
1
0
+0x21
SHORT_ADDR_1[7:0]
SHORT_ADDR_1
Read/Write
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset Value
1
1
1
1
1
1
1
1
Bit
7
6
5
4
3
2
1
0
+0x22
PAN_ID_0[7:0]
PAN_ID_0
Read/Write
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset Value
1
1
1
1
1
1
1
1
Bit
7
6
5
4
3
2
1
0
+0x23
PAN_ID_1[7:0]
PAN_ID_1
Read/Write
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset Value
1
1
1
1
1
1
1
1
