Removing label liner from the rewinder – Printronix SL4M User Manual
Page 257
Removing Label Liner from the Rewinder
257
IMPORTANT
The rewinder supports a maximum diameter of 8 inches of liner
(including rewinder diameter). Exceeding this diameter can cause the
liner to rub on the bottom pan.
Removing Label Liner from the Rewinder
1.
Open the media cover and side cover.
2.
Open the peel-off door by pulling it upward, then forward.
3.
Tear the liner at the tear bar.
4.
Manually turn the rewinder to rewind the remaining liner onto the
rewinder.
5.
Pull the media rewinder clip (along with the liner) off the rewinder.
6.
Remove the liner from the media rewinder clip and discard the liner.
7.
Insert the media rewinder clip into the rewinder.
8.
Close the side cover and media cover.
9.
Close the peel-off door by pushing it towards the rewinder then snapping
it downward.
