224
Chapter 4 ADVANCED USER Menu
Any form elements (text, graphics, or dots) immediately to the right of the
original barcode can force this first attempted placement to be modified.
The replacement barcode will shift left to avoid obstacles on the right
provided that there are also no obstacles on the left.
• Center (factory default). The first attempted position of the center bar of
the replacement barcode will be the same position as the center bar of
the original barcode.
If the replacement barcode is smaller than the original barcode, it will be
replaced as follows:
If the replacement barcode is longer than the original barcode, it will still
be centered, but it will extend beyond the end of the original barcode on
both the left and the right.
Replacement Barcode
Original Barcode
Here is
an
obstacle
(text)
Quiet Zone
Distance
(picket)
Replacement Barcode
Original Barcode
