Section 4
Using the TROY Printer Utility
MICR Solutions User’s Guide -- Document #50-70341-001 Rev. F
4-18
Generating the
TROYmark
™
Background
Pattern (cont.)
(MICR / IRD Secure
EX Printers Only)
T
O SELECT THE
TROY
MARK BACKGROUND PATTERN
:
1. From
the
Main Window, click on Settings, click
on TROYmark Pattern.
2. Click on Options. Choose a basic density level
(light or dark), then select the density
percentage. The pixels in the preview screen
can be clicked ON (black square) or OFF (white
square) to customize the density level of the
background pattern. Up to three user-defined
density level patterns can be saved using
Custom 1 (default), Custom 2, or Custom 3.
3. Click on Update Printer to send these settings
to the printer’s flash-file memory.
4. To verify the correct density level, click on Yes
to print a test page. Click on OK to continue.
NOTE: TROY IRD 9000 1
UP
series printers must have the 100-sheet multipurpose tray installed to use standard-size
forms for printing test and demonstration pages.
TROYmark Pattern
File Options Help
Custom 2
Pattern
Custom 3
Update Printer
Custom 1
Thumbnail
