73
SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS SPECIFICATIONS
Model Numbers Model Numbers Model Numbers Model Numbers Model Numbers I 150-P and 150-P and 150-P and 150-P and 150-P and I 150-S 150-S 150-S 150-S 150-S
Capacity Programmable (up to 6 active digits)
Front Panel controls Full function and numeric membrane keypad
Interface Programmable bidirectional RS232
Case Construction I 150-S Stainless Steel I 150-P Mild Steel
Display Type Vacuum Fluorescent
Display Digits (in/cm) 6 active digits (0.59/1.5 high)
Graduation (Readability) Multiples of 1, 2, 5 with programmable decimal point
Decimal Point 0 to 5 places
Display Update Rate 5 per second
Stabilization Time 3 seconds
Taring Range To capacity by subtraction
Zeroing Range Selectable from 2% to 100% of capacity
Displayed Resolution Programmable 1:10,000 LFT or up to 1:50,000 non-LFT
Internal Resolution 110,000 counts
Overload Indication Err 1
Nominal Overload Capacity 103% of selected capacity
Calibration Unit lb or kg
Span Calibration Push button (10 to 100% of load receiver capacity)
Linearity Calibration Push button (50% of Span Calibration Weight)
Deadload Zero Adjust User accessible potentiometer
Auto Zero Tracking Capture Range Selectable: off, 0.5, 1, or 3 divisions
Vibration Filtering Electronic with 4 selectable levels
Load Cell Input Sensitivity Selectable: 1, 2, or 3 mV/V
Load Cell Excitation 120 mA @ 5V dc (drives up to eight 350 ohm loadcells)
Operating Temperature Range 14° to 104°F/-10° to 40°C
Operating Humidity Range 10 to 90% RH
Operating Power Requirements 100, 120, 220, 240 V ac, 50/60 Hz
Dimensions (W x H x D) (in/cm) 8.8 x 11.8 x 4.5 (21.6 x 30 x 11.5)
Shipping Weight (lb/kg) 13/5.85
Washdown Classification NEMA 4, IP65
NIST HB44 Accuracy Classification III and IIIL for 10,000 divisions
UL Listings 114 and 466
Canadian Weights and Measures Approval number AM 4585 (General Class)
CSA Certification C22.2 No. 151-M1986
