55
Parts Counting With An Auxiliary Sample Scale Parts Counting With An Auxiliary Sample Scale Parts Counting With An Auxiliary Sample Scale Parts Counting With An Auxiliary Sample Scale Parts Counting With An Auxiliary Sample Scale
An Ohaus TP, TS, GT or CT Series precision balance may be used as the sample
scale for parts counting. Any of these balances will provide the I150 with accurate
sample weights for calculating average piece weight.
Required Items: Required Items: Required Items: Required Items: Required Items:
•
Ohaus PRECISION Plus , GT or CT balance with RS-232 interface
•
Blunt end cable for connection to I150 (and computer/printer if used)
Optional Items: Optional Items: Optional Items: Optional Items: Optional Items:
•
Printer or Computer
•
Blunt end cable for connection to sample scale (and I150 if desired)
Cables are available as accessories (see page 74).
RS-232 Connections RS-232 Connections RS-232 Connections RS-232 Connections RS-232 Connections
The following wiring diagram shows possible RS-232 connections for a sample scale,
I150 and optional printer or computer. The only required connections are between the
I150 and sample scale. Since the I150 transmitter and sample scale receiver are not
required, they may be used with a printer, computer or other peripheral device as
shown in the diagram.
If a printer or computer is used, parts count data may be output by the I150 using the
autoprint feature or by pressing the PRINT button. Data will be output in the format
described under “Output Formats” in the RS-232 section of this manual.
*
Ohaus accessory cable AS017-01 does not use CTS connection.
CTS and DTR are tied together.
Sample scale can
receive data from
computer
I150
INDICATOR
I150 receives APW
data from sample scale
I150 sends parts count data
to printer or computer
SAMPLE SCALE*
PRINTER or COMPUTER
