14
TO ACCESS THE MAIN MENU: TO ACCESS THE MAIN MENU: TO ACCESS THE MAIN MENU: TO ACCESS THE MAIN MENU: TO ACCESS THE MAIN MENU:
Press FNCT , then press SETP .
USING MENUS TO USING MENUS TO USING MENUS TO USING MENUS TO USING MENUS TO
CONFIGURE THE I150 CONFIGURE THE I150 CONFIGURE THE I150 CONFIGURE THE I150 CONFIGURE THE I150
Configuring the I150 for your specific
requirements is accomplished through a
series of “menus”. There is one “main”
menu which includes four “submenus”.
The submenus contain the parameters to
be programmed.
The menus are accessed using the front
panel buttons and viewed on the display.
Using these menus, you will program
parameters such as display resolution,
load receiver capacity, the number of load
receivers used, and others. The menus
are also used to calibrate the indicator.
The word “SEtUP” will be displayed which
is the first item on the main menu. The
following table shows the sequence in
which the submenus will appear on the
main menu.
If the word “SEALEd” is displayed, it indi-
cates that the I150 has been configured
and sealed for Legal For Trade use. Setup
parameters may not be changed. They
may only be viewed. See “
Disabling Menu
Changes For Legal For Trade Installa-
tions”.
FUNCTION FUNCTION FUNCTION FUNCTION FUNCTION
SETUP SETUP SETUP SETUP SETUP
UNITS UNITS UNITS UNITS UNITS
