48
Hole Plug
Closing the Cover Closing the Cover Closing the Cover Closing the Cover Closing the Cover
When all connections and settings have
been made, close the cover and fasten
the four cover clamps.
Insert a hole plug (included in accessory
kit) in each liquid tight connector seal
bushing which is not being used, and
tighten the bushing.
Seal Wire
LFT SEALING LFT SEALING LFT SEALING LFT SEALING LFT SEALING
After the indicator and load receiver have
been evaluated and accepted by a weights
and measures official, the indicator must
be sealed as follows:
1. Pass the calibration seal wire through
the small hole in the lip of the cover,
then through the clamp and bracket.
2. Pass the end of the wire through the
lead seal.
3. Seal the unit by squeezing the lead
seal over the wire.
OPERATION OPERATION OPERATION OPERATION OPERATION
Selecting a Weighing Unit Selecting a Weighing Unit Selecting a Weighing Unit Selecting a Weighing Unit Selecting a Weighing Unit
To select one of the available weighing
units for use,
repeatedly press UNITS until the desired
indicator appears on the display.
If the desired unit indicator does not ap-
pear, refer to “Unit Selection” in the
“SCALE SUBMENU” section.
SETUP SETUP SETUP SETUP SETUP
UNITS UNITS UNITS UNITS UNITS
