Ohaus I150-S Indicator - Manual (Page 69)

69
Block Data Output: Block Data Output: Block Data Output: Block Data Output: Block Data Output:
When “bLoc” is selected for “Print” in the rS-232 submenu, the gross, net and tare
weights will be output. If the indicator is in parts counting mode, the number of pieces
and the average piece weight will also be output.
Weight Net,
or Gross,
Field # pcs sp Unit sp Tare or APW CR LF
# of Characters 10 1 2 1 1 1 1
FULL DISPLAY DATA
lb, kg, oz,
cs or PC N = Net
G = Gross
T = Tare
A = APW
Weight/# pieces is right justified and includes
decimal point. If value is greater than 10
characters (including decimal point), question
marks (?) will be output.
NOTE: If time and date are set to ON in the
RS-232 submenu, output will include
time and date first. XX:XX:XX (time)
XX/XX/XX (date)
100 PC (# pcs)
0.010 lb A (apw)
1.002 lb G (gross)
1.002 lb N (net)
0.000 lb T (tare
