IP Director Version 4.4 – User Manual – Part 3: Ingest and Play-Out
EVS Broadcast Equipment – March 2008
Issue 4.4.C
65
C
LIP
T
RANSITION
– T
RANSITION
T
YPE
Note
This field is only available when the channel is set in PGM/PRV mode.
Otherwise, they are dimmed.
The left drop-down list field allows the users to select the clip effect type to be
used for transitions between the elements of the play-list. This effect will be
applied to the audio and video transitions of all elements of the play-list loaded.
The following transition types are available:
Effect Name Description
Cut The cut transition is the default one and does not
display any effect.
Mix In the mix transition, a dissolve effect provides the
transition between the current element and the next
element.
Wipe In the wipe effect, the last frame of the current element
is filled in with the first frame of the next element from
left to right (L-> R) or from the right to the left (R-> L).
C
LIP
T
RANSITION
– T
RANSITION
D
URATION
This right field, the Transition Duration field, makes it possible to specify the
duration of the effect type defined in the Transition Type field. The user can
specify the duration, in seconds and frames, up to 20 seconds.
The transition type is only available for effects other than “cut”. By default, the
transition duration is 00s00, hence no transition is applied.
You can modify the value in two possible ways:
• Select the whole value and enter 4 digits following the pattern 00s00: 2 digits
for seconds, 2 digits for frames.
• Select only the 2 digits for the seconds or the 2 digits for the frames and only
modify this part of the value.
