IP Director Version 4.4 – User Manual – Part 3: Ingest and Play-Out
EVS Broadcast Equipment – March 2008
Issue 4.4.C
111
6.6.3 O
N
-A
IR
P
LAY
-L
IST
M
ODES
LOCK
Changes to
OR
+
+
When the operator clicks on the LOCK button, the play-list interface panel is
locked, and all buttons on the panel become inactive. If a ShuttlePRO is
associated to the on-air channel, its functions will also be inactive. The OSD of
the XT channel will also show a key representing that the play-list is locked.
1
PGM
/
PGM-PRV
MODE
When the operator right-clicks on the Effect Mode button, the following contextual
menu is displayed:
In this menu, PGM/PRV is only available if the on-air channel is a odd numbered
channel of the XT, for example the PGM must be channel 1 and the associated
PRV must be channel 2, channel 3 can be PGM with associated PRV channel 4,
and finally channel 5 can be a PGM with channel 6 as the associated PRV.
PGM/PRV will not become active unless:
•
The operator has the right to control both channels.
•
Both channels are under the control of the IP Director (check 2
n d
control
settings).
•
Either of the 2 channels are locked, by the user or another user
When the operator selects 1 PGM, the play-list will be played in cut mode on only
1 output. If the channel was in PGM/PRV mode, the mode is automatically reset.
When the operator selects PGM/PRV, the play-list will be played on 2 outputs
(effects should be taken into account). The channels are automatically set into
PGM/PRV mode.
PL11/03 Nxt Brk
00:17:13
³
█ █ █ █
█ █ █ █
