Issue 4.4.C
IP Director Version 4.4 – User Manual – Part 3: Ingest and Play-Out
EVS Broadcast Equipment – March 2008
112
Note
In PGM/PRV mode, the PRV could be controlled in PARALLEL with a
secondary device, which could take the control of the channel at any
time.
ON-AIR
When the ON-AIR button is pressed, the ON-AIR status of the channel is set. The
ON-AIR button background is turned from Grey to Red. The OSD of the channel
displays the play-list number in RED.
This only provides a visual warning that the current play-list is On-Air. This can be
selected manually on the tab or can be set using a GPI. For more information on
setting this parameter using a GPI see the section on GPI and Auxiliary Track
settings.
6.6.4 O
N
-A
IR
D
ISPLAYS
I
NFORMATION
D
ISPLAY
S
ETTINGS
The Information displays on the On-Air Panel can display different parameters
dependant on how they have been set in the play-list settings accessed from the
menu Tools > Settings, Play-List – General tab. Please see the ‘Display 3rd time
information in the on-air Panel’ section, on page 155 of the user’s manual for more
information.
Times to transition
If the parameter “Display time till the end of the current element” is checked in the
play-list settings, the following controls are displayed.
Remaining time till the
end of the current
element.
Remaining time till the next element
starts. The difference between the 2
values is the effect duration
.
Remaining time till the next break in
the play-list. If the play-list has no
break, the remaining time till the end
of the play-list is displayed.
