The values initially shown in the dialogue box are either the values for the first
selected element or the default values defined in the play-list settings. For more
information on play-list default settings please refer to the section 6.9.3 “Play-List
– Default Transition Settings”, on page 156.
Still Mode
The still mode setting determines if the play-list should stop on the selected
element and if it should stop where it stops and how it should behave. The options
are:
•
Stop on first frame of current clip
•
Stop on last frame of previous clip
•
Stop on last, wait, jump on first: the play-list will stop on the last
frame of the previous clip, then jump on the first frame of the selected element
after a certain time which is defined in the value box.
•
If no still mode is defined the play-list will play from element to element
using the defined play-list parameters for each element (automatic start mode,
see next section)
Start Mode
If a Still mode is defined, one of the following start modes must be defined on the
selected element. If “Automatically” was already selected when a Still mode is
defined, it will be changed to the “Manual” start mode.
•
Manually: the selected element must be started manually (by a play or play
var command) on the Play-List panel, keyboard or ShuttlePRO controller.
•
On GPI: the selected element will be started when a GPI trigger is received
