IP Director Version 4.4 – User Manual – Part 3: Ingest and Play-Out
EVS Broadcast Equipment – March 2008
Issue 4.4.C
49
For more information on clip creation, refer to section 4.18.1 “How to Create Clips
in the Control Panel”, on page 78.
Window Overview
The Save Clip window is divided into two panes:
• The left pane contains the Clip Information, i.e. clip data in general and in
relation with IP Director.
It is always displayed.
• The right pane contains the Clip Metadata, i.e. clip data based on customer-
specific fields.
Clicking the right area in the Pane Display icon will display this right pane.
Later Access to the Data
Once the clip has been saved, the data will be available in the Clip Information tab
and the Metadata tab of the Control Panel. Most of this data can be edited directly
from these tabs.
4.7.1 F
IELDS IN THE
S
AVE
C
LIP
W
INDOW
The following table describes briefly the data that can be added to clips.
The Clip Information pane contains the following fields:
Field Description
LSM ID LSM ID, i.e. location where the clip will be stored on the
XNet network. This numbering is based on the numbering of
the LSM operational mode.
Name User-defined 24-character name for the clip.
Protect /
Unprotect Button that allows the user to protect or unprotect the
selected clip. When the clip is protected, a message will
warn the users in IP Director or in Multicam not to delete the
clip.
A green Protect icon appears on the left of the Protect
button when the clip is protected by the IP Director protocol.
Keywords Keywords that can be selected from a keyword grid or
dictionary file.
Interest Level User-defined rating of the clip.
Clip Type Type of clip in relation with the Fill and Key function.
The possible values are “Normal”, “Fill”, “Key”.
Send To Destinations where the clip can be transferred to.
Select the check boxes corresponding to the requested
destinations.
