4. In the Paper Type list, select the media type.
5. In the Screening list, select the desired screening type.
6. In the Calibration list, select the desired custom calibration

curve.

7. In the Profile list, select the desired destination profile.
8. Click OK.

Managing calibration tables

Calibrations window

You can view any of the calibration look-up tables (LUTs) that are
stored on the CX print server. You can find the calibration table
information in Tools > Resource Center > Calibrations. This is
part of the Creative Power Kit.

Calibration table list

<Calibration_table_name>

Calibration tables created in the Calibration Wizard.

None

Jobs that have this option selected are processed and
printed without using a calibration table.

Normal

(default table)—This is a default table and cannot be edited.
If a calibration table has not been created for the media
type, and screening method that you are using, the Normal
calibration table is used when you process and print your
job.

Calibration table Info Data tab

This tab includes the following:

Output Density

Measured

The values that are measured from the printed target.

Target

The expected values of the output density.

50

Chapter 7—Managing color
