Reference [Mixer]
ZOOM MRS-802
72
Adjusts the amount of high-range boost/cut.
Range: -12 - 0 - 12 (dB)
Default: 0
• EQ HI F parameter
Adjusts the turnover frequency for high-range boost/cut.
Range: 500 - 18000 (Hz)
Default: 8000
• EQ LO G parameter
Adjusts the amount of low-range boost/cut.
Range: -12 - 0 - 12 (dB)
Default: 0
• EQ LO F parameter
Adjusts the turnover frequency for low-range boost/cut.
Range: 40 - 1600 (Hz)
Default: 125
H INT
• If you press the [ENTER] key while the EQ HIGH parameter
is displayed, EQ HIGH is turned off. Pressing the key once
more turns EQ HIGH on again. In the same way, you can
switch EQ LOW between on and off with the [ENTER] key
while the EQ LOW parameter is displayed.
• Immediately after switching the display, the audio track or
the drum track that was selected before will still be
selected. If necessary, switch to another track.
5.
Set the EQ parameter for other audio tracks or the
drum track in the same way.
6.
When you have finished adjusting settings, press
the [EXIT] key.
The unit returns to the main screen.
Adjusting depth of send/return effect
This section explains how to adjust the effect depth by
setting the volume that is sent from each channel to the send/
return effects (chorus/delay, reverb). Raising the send level
will produce a deeper effect.
1.
Press the [CHORUS/DELAY] key or [REVERB] key
to select a patch for the send/return effect.
The display changes and shows the currently selected patch
of the selected effect (chorus/delay or reverb).
2.
Turn the dial to select the patch you want to use.
You can also select a patch by using the PATCH SELECT
[ Q ]/[ W ] keys in the effect section.
When you have selected the patch, press the [EXIT] key.
3.
Press the [TRACK PARAMETER] key in the track
parameter section and use the cursor up/down
keys to bring the following indication onto the
display.
• Adjusting the chorus/delay send level
• Adjusting the reverb send level
4.
Press the status key for the audio track or the
drum track to which you want to apply the effect.
5.
Turn the dial to select the effect depth.
Higher values result in more effect depth (stronger effect).
The range and default values for the parameters are shown
below.
• CHORUS/DELAY SEND: 0 - 100 (default: 0)
• REVERB SEND: 0 - 100 (default: 0)
TR1 TR1
EQ HI F
EQ HI F 8000
TR1 TR1
EQ LO G
EQ LO G 0
TR1 TR1
EQ LO F
EQ LO F 125
TR1 TR1
CHO SEND
CHO SEND 0
TR1 TR1
REV SEND
REV SEND 0
