Reference [Mixer]
ZOOM MRS-802
71
4.
When you have finished adjusting the panning
value, press the [EXIT] key.
The unit returns to the main screen. The function of the PAN
parameter changes as follows, depending on the number of
inputs that are currently turned on, and on the number of
recording tracks that are currently selected.
• When no recording track is selected
For the signal that is sent from the input mixer to the L/R
channels of the MASTER OUTPUT jacks, the PAN
parameter will adjust the panning position (if the input is in
mono) or the balance (if the input is in stereo).
• When two mono tracks are selected as recording
tracks
For the signal that is sent from the input mixer to the two
tracks, the PAN parameter will adjust the panning position
(if the input is in mono) or the balance (if the input is in
stereo).
• When one mono track is selected as recording track
The PAN parameter will have no effect.
Basic operation of the track
mixer
Adjusting the volume/pan/EQ
For each channel, you can adjust the volume, panning
(stereo position between L/R channels), and EQ (equalizer).
1.
To adjust the volume of the audio track or the drum
track, operate the respective fader.
2.
To adjust the panning position of a track or the
drum track, press the [TRACK PARAMETER] key in
the track parameter section and use the cursor up/
down keys to bring the following indication onto
the display.
3.
Press the status key for the audio track or the drum
track, and turn the dial to edit the value of the PAN
parameter.
The PAN parameter can be adjusted in a range of L100 (far
left) - 0 (center) - R100 (far right).
To adjust the pan of another track or the drum track, repeat
steps 2 - 3.
H INT
• If the stereo link function (
→ p. 73) is activated for the
selected target track (audio track or drum track), the PAN
parameter adjusts the left/right channel balance.
• In the parameter screen you can also use the cursor left/
right keys to select the audio track or the drum track and
the cursor up/down keys to switch parameters.
4.
To adjust EQ, use the cursor up/down keys to bring
up the following screen and then use the dial to
adjust the setting.
• EQ HI G parameter
TR1 TR1
PAN
PAN 0
TR1 TR1
EQ HI G
EQ HI G 0
