Appendix
ZOOM MRS-802
149
● MODULATION/DELAY module
Parameter Description
Type Parameter
CHORUS
DEPTH RATE MIX
Stereo chorus with clear sound and great spaciousness.
FLANGER
DEPTH RATE FB
An effect that adds a pronounced character and modulation to the sound.
PHASER
RATE COLOR
An effect that adds a swooshing modulation to the sound.
TREMOLO
DEPTH RATE CLIP
An effect that cyclically varies the volume.
PITCH
SHIFT TONE BALANCE
An effect that modifies the pitch of the direct sound.
RingMod
RATE BALANCE
An effect that produces a metallic resonance.
EXCITER
FREQ DEPTH LowBoost
An effect that gives the sound more focus and spatial definition.
AIR
SIZE TONE MIX
Simulates the effect of air on the room resonance, giving the sound spatial depth.
DELAY
TIME FB MIX
A delay effect with a maximum of 500 ms.
DOUBLE
TIME TONE MIX
A doubling effect that allows the delay time to be set in 1-ms steps up to 100 ms.
Parameter Name Setting Range Parameter Description
DEPTH 0 – 10 Adjusts the depth of the effect.
RATE 1 – 30 Adjusts the speed of the effect.
COLOR 1 – 4 Specifies the type of phase tone.
CLIP 0 – 10 Emphasizes the effect.
SHIFT -12.0 – 24.0
Adjusts the amount of pitch shift produced by the pitch shifter. 1.0 corresponds
to a semitone.
BALANCE 0 – 30 Adjusts the balance between the direct sound and effect sound.
FREQ 1 – 5 Adjusts the frequency.
LowBoost 0 – 10 Emphasizes the low-frequency range.
SIZE 1 – 10 Adjusts the spatial width.
FB
TYPE = FLANGER : -10 – 10
Adjusts the feedback amount.
TYPE = DELAY : 0 – 10
TIME TYPE = DELAY : 1 – 50 Adjusts the delay time (x 10 ms)
TYPE = DOUBLE : 1 – 100 Adjusts the delay time (x 1 ms)
TONE 0 – 10 Adjusts the tone.
MIX 0 – 30 Adjusts the mix amount of the effect sound.
