Reference [Effects]
ZOOM MRS-802
104
COMP PRE AMP/DRIVE EQ
EQ
MODULATION/DELAY
MODULATION/DELAY
MODULATION/DELAY
ZNR, VOL PDL, PAT LVL
ZNR, VOL PDL, PAT LVL
EQ ZNR, VOL PDL, PAT LVL
EQ ZNR, VOL PDL, PAT LVL
COMP/LIM
COMP/LIM
COMP/LIM
MICPRE+DE-ESSER
MICPRE DOUBLING
ISOLATOR
3BAND COMP/
Lo-Fi
NORMALIZER DIMENSION/
RESONANCE
EQ ZNR, VOL PDL, PAT LVL
COMP COMP
COMP/LIM COMP/LIM
COMP Lch COMP Lch
COMP/LIM COMP/LIM
CMP/LoFi CMP/LoFi
PRE/DRV PRE/DRV
MIC PRE MIC PRE
MicPre L MicPre L
ISOLATOR ISOLATOR
NORMLZR NORMLZR
3BandEQ 3BandEQ
3BandEQ 3BandEQ
MOD/DLY MOD/DLY
MOD/DLY MOD/DLY
MOD/DLY MOD/DLY
DIM/RESO DIM/RESO
DOUBLE L DOUBLE L
TOTAL TOTAL
TOTAL TOTAL
EQ Lch EQ Lch TOTAL TOTAL
3BandEQ 3BandEQ TOTAL TOTAL
3BandEQ 3BandEQ TOTAL TOTAL
CLEAN
DIST
ACO/BASS SIM
BASS
MIC
DUAL MIC
LINE
MASTERING
Algorithm Module/Display
N OTE
The table above shows the condition when the effect module
is On. When the effect module is Off, the second line of the
display shows “-OFF-”.
4.
If you want to switch the effect type for the
selected module, turn the dial to select the desired
effect type.
H INT
• If the contents of a patch have been edited, the “EDIT”
indicator in the upper part of the display will change to
“EDITED”.
• If “TOTAL” is shown on the display, you can use the cursor
up/down keys to select PAT LVL, ZNR, or VOL PDL.
N OTE
Some effect modules have only one effect type. For such
modules, there will be no screen for selecting the effect type.
5.
Use the cursor up/down keys to select the effect
parameter that you want to edit.
When you use the cursor up/down keys, a setting screen for
the effect types and parameters for this module is shown.
The following diagram shows an example of what appears
on the display when you have selected the DEPTH
parameter of the “FLANGER” effect.
6.
Turn the dial to change the setting.
For details on the effect types that can be selected for each
effect module, and on the effect parameters of each type,
refer to the appendix (
→ p. 145 – 153) at the end of this
manual.
7.
To switch the module On/Off setting, bring the
module onto the display and press the [ENTER]
key.
When the effect module has been set to Off, the effect type
name is shown as “-OFF-” on the display. If you press the
[ENTER] key once more in this condition, the setting is
returned to On.
N OTE
If “TOTAL” is shown on the first line of the display, you can
adjust the ZNR/VOL PDL module setting and the patch level.
Switching the effect module On/Off is not possible in this
case.
8.
Repeat steps 3 - 7 to make the desired edits for
other modules.
Effect type name
MOD/DLY MOD/DLY
FLANGER
FLANGER
Setting value
FLANGER FLANGER
DEPTH
DEPTH 2
FLANGER FLANGER
-OFF-
-OFF-
